IFM Pressure sensor with display PN-100-SEN14-QFRKG/US/ /V PN:PN7292 With Best Price
Techincal Information:
Two switching outputs, one of them with IO-Link communication interface
Red/green display for clear identification of the acceptable range
The process connection can be rotated for optimum alignment
With long-term stability thanks to high overload protection
Robust design for use in harsh industrial environments
| Product characteristics | |
|---|---|
| Output signal | switching signal; IO-Link; (configurable) |
| Measuring range | 0...100 bar0...1450 psi0...10 MPa |
| Process connection | threaded connection 1/4" NPT internal thread |
| Application | |
| Special feature | Gold-plated contacts |
| Measuring element | ceramic-capacitive pressure measuring cell |
| Application | for industrial applications |
| Media | Liquids |
| Conditionally suitable for | use in gases at pressures > 25 bar only on request |
| Medium temperature [°C] | -25...80 |
| Min. bursting pressure | 650 bar9400 psi65 MPa |
| Pressure rating | 300 bar4350 psi30 Mpa |
| Type of pressure | relative pressure |
| MAWP (for applications according to CRN) [bar] | 125 |
| Electrical data | |
| Operating voltage [V] | 18...30 DC; (according to EN 50178 SELV/PELV) |
| Current consumption [mA] | < 35 |
| Min. insulation resistance [MΩ] | 100; (500 V DC) |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time [s] | 0.3 |
| Integrated watchdog | yes |
| Inputs / outputs | |
| Number of inputs and outputs | Number of digital outputs: 2 |
| Outputs | |
| Total number of outputs | 2 |
| Output signal | switching signal; IO-Link; (configurable) |
| Electrical design | PNP/NPN |
| Number of digital outputs | 2 |
| Output function | normally open / normally closed; (parameterisable) |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 150; (200 (...60 °C) 250 (...40 °C)) |
| Switching frequency DC [Hz] | < 170 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
| Measuring/setting range | |
| Measuring range | 0...100 bar0...1450 psi0...10 MPa |
| Factory setting / CMPT = 2 | |
| Set point SP | 1...100 bar10...1450 psi0.1...10 MPa |
| Reset point rP | 0.5...99.5 bar5...1445 psi0.05...9.95 MPa |
| Min. difference between SP and rP | 0.5 bar10 psi0.05 MPa |
| In steps of | 0.5 bar5 psi0.05 MPa |
| Status_B High Resolution / CMPT = 3 | |
| Set point SP | 0.8...100 bar12...1450 psi0.08...10 MPa |
| Reset point rP | 0.3...99.5 bar5...1443 psi0.03...9.95 MPa |
| Min. difference between SP and rP | 0.5 bar8 psi0.05 MPa |
| In steps of | 0.1 bar1 psi0.01 MPa |
| Accuracy / deviations | |
| Switch point accuracy [% of the span] | < ± 0,5 |
| Repeatability [% of the span] | < ± 0,1; (with temperature fluctuations < 10 K) |
| Characteristics deviation [% of the span] | < ± 0,25 (BFSL) / < ± 0,5 (LS); (BFSL = Best Fit Straight Line; LS = limit value setting) |
| Hysteresis deviation [% of the span] | < ± 0,25 |
| Long-term stability [% of the span] | < ± 0,05; (per 6 months) |
| Temperature coefficient zero point [% of the span / 10 K] | < ± 0,2; (-0...80 °C) |
| Temperature coefficient span [% of the span / 10 K] | < ± 0,2; (-0...80 °C) |
| Response times | |
| Delay time programmable dS, dr [s] | 0...50 |
| Software / programming | |
| Parameter setting options | hysteresis / window; normally open / normally closed; switching logic; switch-on/switch-off delay; Damping; Display unit |
| Interfaces | |
| Communication interface | IO-Link |
| Transmission type | COM2 (38,4 kBaud) |
| IO-Link revision | 1.1 |
| SDCI standard | IEC 61131-9 |
| SIO mode | yes |
| Required master port type | A; (when pin 2 not connected: B) |
| Supported DeviceIDs | Type of operationDeviceIDFactory setting / CMPT = 2452Status_B High Resolution / CMPT = 3629 |
| Note | For further information please see the IODD PDF file under "Downloads" |
| Factory setting / CMPT = 2 | |
| Profiles | Smart Sensor: Process Data Variable; Device Identification, Device Diagnosis |
| Min. process cycle time [ms] | 2.3 |
| IO-Link resolution pressure [bar] | 0.1 |
| IO-Link resolution pressure [MPa] | 0.01 |
| IO-Link process data (cyclical) | functionbit lengthpressure14binary switching information2 |
| IO-Link functions (acyclical) | application specific tag |
| Status_B High Resolution / CMPT = 3 | |
| Profiles | Smart Sensor ED2: Digital Measuring Sensor (0x000A), Identification and Diagnosis (0x4000) |
| Min. process cycle time [ms] | 3 |
| IO-Link resolution pressure [bar] | 0.05 |
| IO-Link resolution pressure [MPa] | 0.005 |
| IO-Link process data (cyclical) | functionbit lengthpressure16device status4binary switching information2 |
| IO-Link functions (acyclical) | application specific tag |
| Operating conditions | |
| Ambient temperature [°C] | -25...80 |
| Storage temperature [°C] | -40...100 |
| Protection | IP 65; IP 67 |
| Tests / approvals | |
| EMC | DIN EN 61000-6-2DIN EN 61000-6-3 |
| Shock resistance | DIN EN 60068-2-2750 g (11 ms) |
| Vibration resistance | DIN EN 60068-2-620 g (10...2000 Hz) |
| MTTF [years] | 286 |
| UL approval | UL Approval no.J002 |
| Pressure Equipment Directive | Sound engineering practice; can be used for group 2 fluids; group 1 fluids on request |
| Mechanical data | |
| Weight [g] | 260 |
| Materials | stainless steel (1.4404 / 316L); PBT+PC-GF30; PBT-GF20; PC |
| Materials (wetted parts) | stainless steel (1.4404 / 316L); ceramics; FKM |
| Min. pressure cycles | 100 million |
| Tightening torque [Nm] | 2...3 turns after hand-fastening; recommended tightening torque; depends on lubrication, seal and pressure rating |
| Process connection | threaded connection 1/4" NPT internal thread |
| Restrictor element integrated | no (can be retrofitted) |
| Displays / operating elements | |
| Display | Display unit3 x LED, green (bar, psi, MPa)switching status2 x LED, yellowmeasured valuesalphanumeric display, red/green 4-digit |
| Remarks | |
| Pack quantity | 1 pcs. |
