Manufacturer: Sew-Eurodrive
Type: Helical Worm Gear Motor
Model: SA57DRN90L4
Serial Number: 50.7443146504.0001.17

Speed 50Hz [r/min]: 1461 / 103
Speed 60Hz [r/min]: 1767 / 124
Total Ratio [i]: 14.24 / Finite
Ma Max [Nm]: 169
Output Torque 50Hz [Nm]: 125
Output Torque 60Hz [Nm]: 104
Service Factor SEW-FB: 1.35 / 1,65
Mounting Position: M1A
Lubricant / -Volume [L]: CLP 680 Miner.Oil / 0,50

Gear Unit: SA57
Hollow Shaft: 30mm
Design: Hollow Shaft

Motor: DRN90L4
Motor Power [kW]: 1.5
Cyclic Duration Factor: S1
Multi Range-Voltage 50Hz [V]: 220-230 Delta / 380-400 Star
Rated Current [A]: 6.00 / 3.45
Multi Range-Voltage 60Hz [V]: 254-266 Delta / 440-460 Star
Rated Current [A]: 5.20 / 3.00
Cos Phi: 0,74 / 0,70
Thermal Cl.[°C]/Enclosure [IP]: 130(B) / 54
Service Factor Motor: 1.0
International Efficiency Class: IE3
Efficiency 50Hz at 50/75/100% Pn [%]: 84,6 / 86,1 / 85,6
Efficiency 60Hz at 50/75/100% Pn [%]: 83,5 / 85,9 / 86,5
Design Specification: Europe (CE)/USA (UR) /Canada (CSA)
Terminal Box: Terminal Box Lower Part Made of Aluminum with Tapped Hole 1xM25, 1xM16
CT Speed Range: 300-1800RPM
Weight [kg]: 33.0
