MTL MA3145-120-2-R surge protection With Best Price In Ready Stock

Introduce of MTL MA3145-120-2-R

The MA3100 range offers cost effective, DIN rail mounted, surge protection for applications described by IEC 61312 The Class II range of surge arrestors fit in to the cascade philosophy along side Class I & Class III devices.

All modules are DIN rail mounted for ease of installation and have very small footprints therefore minimising the space required. Each device is simply connected in parallel with the power.

The Class II surge current arrester is designed to work as both a standalone device and in cascade coordination with Class I lightning arrester. A single width module withstands surge currents up to 40,000A with an 8/20µs waveform. Class II arresters are available in single width modules for maximum user flexibility, double width modules for all-mode protection on single phase systems and quad

width modules for all-mode protection on three phase systems.The Class II modules have remote monitoring capabilities as a standard feature. Voltage free, normally open, normally closed contacts can be

used for a variety of monitoring tasks.

The MA3145 Class II surge current arrestor has a Short Circuit Current rating (SCCR) of 200kA which removes the need for external

fusing and reduces installation cost.

Feature of MTL MA3145-120-2-R

• Space saving design, DIN-rail mounting

• Full range of AC mains power applications

• Coordinated surge protection to IEC 61312;rated according to IEC 61643

• UL1449 3rd Edition, Type 4 Recognized Component, VZCA2 & VZCA8, File E315539

• 200kA Short Circuit Current Rating
