100% Brand New Pepperl+Fuchs PVM58N-YY1AGR0BN-1213 Multiturn absolute encoder With Best Price In Ready Stock

Absolute rotary encoders provide a distinctly coded numerical value for each shaft position. In positioning tasks in particular, the absolute encoders relieve the controller of computation tasks and keep costs down by eliminating the need for additional input components.

Moreover, reference runs when the machine is switched on or after power failures are no longer required as the current position value is available immediately. Parallel absolute encoders transmit the position value to the analyzing electronics through several parallel cables. Serial absolute encoders transmit their output data via standardized interfaces and protocols.

In the past, point-to-point connections were frequently set up for serial data transmission but today fieldbus systems are being used more often.

Interfaces:

The Pepperl+Fuchs rotary encoder portfolio includes the most varied range of current interfaces for absolute encoders to be found on the market:

•   Parallel Interface

•   SSI-Interface

•   AS-Interface

•   CAN

•   DeviceNet

•   Ethernet

•   PROFIBUS

•   PROFINET

Function: PVM58N-YY1AGR0BN-1213

This series of PROFIBUS rotary encoders is based on the modern fast technology of singleturn sampling and the mechanical gear box of the multiturn unit. The absolute encoder corresponds to the PROFIBUS profile for encoders, order no. 3.062. Operation is supported based on Class 1 and Class 2.

For operation based on Class 1, position data and diagnostic data bytes 1 ... 16 are available. In addition, the direction of the code can be selected as either cw ascending (clockwise rotation, code course ascending) or cw descending (clockwise rotation, code course descending).

If the rotary encoder is operated according to Class 2, additional functions to those from Class 1 are available. These include scaling of the resolution per revolution and the overall resolution, as well as the preset function. In addition, expanded diagnostic reporting is supported.

Besides, the rotary encoder offers extended functionalities such as speed transfer, extended scaling functions, programmable limit switches and a commissioning mode.

The removable connecting hood contains a slide switch for setting the terminating resistor and the rotary switches for setting the address. Assign a fixed address and bus termination to the encoder with this switches.

The device is designed for shaft mounting and is available in servo flange or clamping flange design.

Feature of PVM58N-YY1AGR0BN-1213

•   Industrial standard housing ∅58 mm

•   PROFIBUS interface

•   25-bit multiturn

•   Speed transfer

•   Extended scaling functions

•   Programmable limit switches

•   Commissioning mode

•   Clamping flange

Datasheet excerpt: Technical data of  PVM58N-YY1AGR0BN-1213
